Mango Cake Production Line
Application
Mango cake is a dessert that combines the sweet sweetness of mango with the rich aroma of milk. It has a soft, glutinous and delicate texture, making it suitable for afternoon tea or as a snack. The production steps are: boiling sugar, stirring, cooling and shaping, cutting into pieces, and packaging.
HANYUAN “Mango Cake Production Line” is mainly applied in the slice cutting of mango cake, donkey-hide gelatin pastry, dates&walnut pastry, mixing of dry&adhesive materials, forming&cooling&cutting, pillow packaging. This production line applies the Gas or Steam Planet-stirring-pot to concentrate the pastry gently. This production line adopts Air-conditioner cooling tunnel to actively cool the bar slab, which is suitable for the frozen forming of viscous and sticky materials. This production line adopts strip-cutting-knives, and servo-vertical-guillotine knife to cut the slab into slice. This production line adopts fully automatic pillow packaging with transverse&longitudinal separating roller to achieve the fast sorting and arrangement of bars, high-speed packaging.
Machinery Introduction
Sample
Machine Including
 |  |  |
| Sugar Cooking | Mixing Machine | Conveyor |
 |  | |
| Cutting Machine | Packaging Machine | |
Characteristics
1.This production line is equipped with an active cooling function.
2. This production line is equipped with a large multi-roll leveling machine for flattening and ensuring uniform thickness.
3. This production line includes feeding, cooling, spreading, leveling, cooling and cutting to form continuous packaging.
4. The size of this production line can be adjusted to meet the production needs of different product specifications.
5. This production line adopts PLC + touch screen + frequency conversion control, featuring automatic cutting, which saves time and effort, and is economical and convenient.
6. This production line is equipped with an automatic pillow packaging machine, featuring complete material management functions and fast packaging speed. The bag size is adjustable, the packaging speed is adjustable, the packaging forming effect is good, it saves labor and has a high cost performance.
Technical Parameter
| Item | Value |
| Voltage | 380V/50Hz |
| Power | 100kW |
| Capacity | 300~500kg/h |
| Area | 30×6m |
| Manpower | 4~6people |
